Tracking your equipment (gears) should evolve into objective metrics to make the best decisions. On-site measurement of gear wear is often done without a suitable tool. NOVEXA offers you the supply of a control case including for your pinion/crown harnesses:
- Control templates to measure wear and quantify profile deformation and the wear rate to within 0.05 mm per year
- The sheets that allowed the machining of the tools
- An explanatory sheet for use and calculation
- Dedicated software for data entry and the establishment of a tracking sheet.
In order to make your templates, we need the following data:
- Module
- pressure angle
- Number of pinion and crown teeth
- Outer diameters pinion and crown
- Pinion and crown widths
- Helix angle (right or left helix on pinion)
These templates are real anticipatory tools. They combine perfectly with the reduction of maintenance expenses thanks to better estimation and anticipation of wear.
Ils permettent en outre, de contrôler :
- Wear V1 (maximum wear), V2 (minimum wear) and V3 (loss of thickness).
- The deformation of the profiles which informs us about the vibratory conditions.
- The wear rate. This allows us to act directly on the life of the equipment
- The remaining thickness to decide the most suitable option, reprofiling, reversal or replacement.
To remember
- 200 factories equipped with inspection jigs
- 15 minutes for a profile check
- An associated control software
